Norco MITX-6922 - Display Port（Vga， DVI，LVDS

MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset
12
RXD5
23
24
RTS5
TXD5
25
26
CTS5
DTR5
27
28
RI5
GND
29
30
GND
DCD6
31
32
DSR3
RXD6
33
34
RTS6
TXD6
35
36
CTS6
DTR6
37
38
RI6
GND
39
40
GND
2.5.3 Display Port（VGA， DVI，LVDS）
VGA：
Pin
Signal Name
Pin
Signal Name
Pin
Signal Name
1
RED
6
GND
11
NC
2
GREEN
7
GND
12
SDA
3
BLUE
8
GND
13
HSYNC
4
NC
9
+5V
14
VSYNC
5
GND
10
GND
15
DDCCLK
VGA、DVI
LVDS
HDMI
