MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset
33
End of Post Enable
The status bit transmitted to ME, which is required for AMT remote installation system
3.2.6 USB Configuration
Enable or Disable the USB EHCI
(USB 2.0) functions.
One EHCI controller must always
be enabled.
USB Devices：
1 Drive , 2 Hubs
EHCI1 Controller [Enabled]
EHCI2 Controller [Enabled]
Legacy USB Support [Enabled]
Mass Storage Devices;
KingstonDT 101 G2 PMAP [Auto]
→←：Select Screen
↑↓：Select Item
Enter：Select
+/-：Change Opt.
F1：General Help
F9：Optimized Defaults
F10：Save&Exit
ESC：Exit
Version 2.10.1208. Copyright（C）2010 American Megatrends，Inc.
EHCI1/2 Controller
[Enabled]: Allow using USB EHCI transport protocol, transmission rate up to 480Mpbs
[Disabled]:USB2.0 port is forbidden，the traditional transmission rate is12Mpbs.
Legacy USB Support
Legacy USB supports setting. To support USB devices in DOS mode, such as USB flash
disk, USB keyboard, select this option as [Enabled] or [Auto]. Otherwise, select [Disabled].
Mass Storage Devices
Set specific type for connecting USB devices，Set value：[Auto][Floppy][Forced FDD][Hard
Disk][CD-ROM]，default: Auto.
3.2.7 IT8783F Supper IO Configuration
