MITX-6922 Mini-ITX Motherboard Based on Intel QM67/QM77 Chipset
34
IT8783F Super IO Configuration
Set Parameters of Serial Port 1
（COMA）
IT8783F Super IO Chip IT8783F
Serial Port 1 Configuration
Serial Port 2 Configuration
Serial Port 3 Configuration
Serial Port 4 Configuration
Serial Port 5 Configuration
Serial Port 6 Configuration
→←：Select Screen
↑↓：Select Item
Enter：Select
+/-：Change Opt.
F1：General Help
F9：Optimized Defaults
F10：Save&Exit
ESC：Exit
Version 2.10.1208. Copyright（C）2010 American Megatrends，Inc.
Serial Port 1 Configuration
1）Serial Port
[Enabled] or [Disabled] serial port.
2）Device Setting（read only）
Display interrupt and address of serial port
3）Change Setting
To change the serial port setting. It is recommended to select Auto by default.
The following Serial Port 1-6 Configuration settings are the same as above.
3.2.8 IT8783F H/W Monitor
BIOS SETUP UTILITY
PC Health Status
CPU Temperature : +43℃
SYS Temperature : + 36℃
