Installation
A1-23
E 2000 Nordson Corporation
All rights reserved
41-3000V
Issued 5/00
A3EN-04-[3V-A-AAXP]-12
CAUTION: Use 0.34--0.25 mm
2
(22--24 AWG) stranded wire.
Using a different wire size can cause internal stress-related
damage to the unit
1. Make sure that your system meets the following requirements:
S Trigger signals are 9 to 24 VDC.
S The enable/disable device is an active low signal.
S Each solenoid valve (or other gun driver device) is rated for no
more than 1 A at 24 VDC.
WARNING: Risk of equipment damage, personal injury or
death. Install a strain relief to protect wires from being
damaged by the edges of the knockout hole.
CAUTION: Circuit boards can be easily damaged. Avoid any
contact with circuit boards when removing a knockout hole plug.
2. If you have not already done so, remove and discard the plug from a
knockout hole on either the back side or the bottom of the unit
(whichever is most convenient for your operation) and install a strain
relief in the hole. Refer to the following table for the appropriate size
strain relief.
NOTE: Your unit may have several knockout holes. You should
route your pattern control wiring through a larger hole.
Size of Knockout Hole
Size of Strain Relief to Install
23 mm (
15
/
16
in.) PG-16 or
1
/
2
-in. trade size
29.5 mm (
15
/
32
in.) PG-21
35 mm (1
3
/
8
in.) 1-in. trade size
To Next Page
