Nortel SR1001 - Pinouts: V.35 Connector (DTE)

61
SR1001 Installation Guide
Version 8.3.5
Table 30 Pinouts: V.35 Connector (DTE)
Pin Signal Direction
17 SD- —>
18 SD+ —>
19 SCTE- —>
20 SCTE+ —>
23 SCT- <—
24 SCT+ <—
25 SCR- <—
26 SCR+ <—
27 RD- <—
28 RD+ <—
33 RLSD <—
34 DSR <—
35 CTS <—
42 RTS —>
43 DTR —>
44 LL —>
45 ground
46 ground
48 ground
49 mode 1
50 mode 0
51 ground
52 mode DCE
53 TxC/NIL
54 RxC_TxCE
55 RxD/TxD
56 ground
Unreferenced pins are not
connected.
