Notifier ACM-24AT Installation Manual

Product Overview
PN 15842:K 7/23/2002 17
Table 2-1 Backbox Sizing Guide
Part
Number Height Width Depth Color
ABS-1
8.5" (21.59 cm) 4.5" (11.43 cm)
1.375" (3.49 cm) Gray
ABS-1B 2.0" (5.08 cm) Black
ABS-2
8.5" (21.59 cm) 8.920" (22.66 cm)
1.375" (3.49 cm) Gray
ABS-2B 2.0" (5.08 cm) Black
ABS-4D,
ABS-4DR
Box: 11.97" (30.40 cm)
Door: 11.97" (30.40 cm)
Box: 19.87" (50.47 cm)
Door: 19.87" (50.47 cm)
Box: 3.5" (8.89 cm)
Door: 1.25" (3.18 cm)
Black
or
Red
ABS-1T
9.938" (25.24 cm) 4.625" (11.75 cm)
2.5" (6.35 cm) Gray
ABS-1TB 2.5" (6.35 cm) Black
ABF-1,
ABF-1B
Box: 9.938" (25.24 cm)
Trim plate:
11" (27.94 cm)
Box: 4.625" (11.75 cm)
Trim plate:
6.25" (15.875 cm)
2.5" (6.35 cm)
Gray,
Black
ABF-2
Box: 9.938" (25.24 cm)
Trim plate: 11" (27.94 cm)
Box: 9.188" (23.34 cm)
Trim plate:
10.625" (26.99 cm)
1.375" (3.49 cm) Gray
ABF-2B 3.75" (9.525 cm) Black
ABF-4 Box: 9.938" (25.24 cm)
Trim plate:
11.0" (27.94 cm)
Box: 17.750" (45.09 cm)
Trim plate:
19.375" (49.21 cm)
2.5" (6.35 cm)
Gray
ABF-4B Black
ABF-1D,
ABF-1DB
Box: 9.938" (25.24 cm)
Door: 11.0" (27.94 cm)
Box: 4.625" (11.75 cm)
Door: 6" (15.24 cm)
Box: 2.5" (6.35 cm)
Door: 0.75" (1.9 cm)
Gray,
Black
ABF-2D
Box: 9.938" (25.24 cm)
Door: 11.0" (27.94 cm)
Box: 9.188" (20.80 cm)
Door: 10.375" (26.35 cm)
Box: 2.5" (6.35 cm)
Door: 0.75" (1.9 cm)
Gray
ABF-2DB
Box: 3.750" (9.53 cm)
Door: 0.75" (1.9 cm)
Black
