Notifier ACM-24AT Installation Manual

NCA Systems
PN 15842:K 7/23/2002 85
U.4 Programming the NCA for Remote Annunciation
Annunciator points must be programmed from the NCA before the annunciators
will function. The NCA employ the following format for annunciator points:
Note: To program the annunciators into NCA memory, and to map system
points and software zones to annunciator points, refer to the NCA Manual.
Note: When using the NCA to annunciate points on the AM2020/AFP1010 over
the network, enable state reporting in the AM2020/AFP1010 panel for control
module points and “NONA”/”NOA” module points; refer to the NCA Manual
for instructions.
A(xx) P(yy)
Annunciator address
In the range of 1-32,
as set on the
annunciator’s rotary
decimal switches.
Annunciator Points per Module
*Note: Points 65-96 are not used unless ACS device is programmed for 96 points.
ACM-24AT,
Points 1-24
First AEM-24AT,
Points 25-48
Second
AEM-24AT,
Points 49-72*
Third AEM-24AT,
Points 73-96*
ACM-48A,
Points 1-48
AEM-48A,
Points 49-96*
ACM-16AT,
Points 1-16
First AEM-16AT,
Points 17-32
Second
AEM-16AT,
Points 33-48
Third AEM-16AT,
Points 49-64
ACM-32A,
Points 1-32
AEM-32A,
Points 33-64
