Panel Operation
30 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
6.3.3.7 SERVICE MENU – LIST – LIST – ANALOG
This menu will list all Analog addressable loops (1 –10), you can then select detectors or modules, then read
status or change or test a point.
1) LOOP 1
2) LOOP 2
3) LOOP 3
4) LOOP 4
5) LOOP 5
6) LOOP 6
7) LOOP 7
8) LOOP 8
9) LOOP 9
0) LOOP 10
ANALOG LIST - LOOP
01 OCT 1999 14:44:37
A = 0
F = 0
I = 0
N = 0
SELECT
20 JULY 2002 14:44:37
USE BUTTONS/NUMBERS TO SELECT LOOP
DAY MODE
BACKUP DOWN
Actions:
 Use the UP and DOWN buttons to scroll through
the Analog loop list.
 Use the SELECT button to select the loop to list.
 Alternatively press 1 through 9 (use 0 to
select LOOP 10).
Once you have selected the loop you will be prompted to select detectors or modules as follows:
SELECT DEVICE ON LOOP 1:
1) DETECTOR
2) MODULE
ANALOG LIST – DETECTOR/MODULE
20 JULY 2002 14:44:37
A = 0
F = 0
I = 0
N = 0
SELECT
USE BUTTONS/NUMBERS TO SELECT DEVICE
DAY MODE
BACKUP DOWN
Actions:
 Use the UP and DOWN buttons to select option.
 Use the SELECT button to select the loop to list.
Note: AFP-2802 supports a maximum of 4 loops. Loops 5 to 10 are not displayed on AFP-2802.
