Panel Operation
AFP-2800/2802 Manual – P/N 11249 11-Mar-08 31
6.3.3.7.1 SERVICE MENU – LIST – LIST – ANALOG – DETECTORS
This screen will provide a list of all Analog addressable detectors (1-159) on the loop selected showing the name
of each detector alongside.
Note: AFP-2802 supports a maximum of 99 detectors per loop. Detectors 100 to 159 are not displayed on AFP-2802.
An alarm, fault or isolate flag will also appear on the right hand side of the line for easy status reference.
From this screen you can do a live read status of the point or change the configuration of the point.
Detectors that are not installed are listed as “NOT INSTALLED”, performing a change on a detector will
automatically install it.
USE BUTTONS TO SELECT DEVICE:
L1D1 FIRE CONTROL ROOM
L1D2 APARTMENT 1 BATHROOM F
L1D3 APARTMENT 1 LIVING AREA A
L1D4 APARTMENT 1 BEDROOM
L1D5 APARTMENT 2 BATHROOM
L1D6 APARTMENT 2 LIVING AREA
L1D7 APARTMENT 2 BEDROOM
L1D7 SECURITY OFFICE
L1D8 CARPARK DETECTOR #1 I
L1D9 CARPARK DETECTOR #2
L1D10 CARPARK DETECTOR #3
L1D11 LIFT MOTOR ROOM
L1D12 NOT INSTALLED
L1D13 NOT INSTALLED
L1D14 NOT INSTALLED
L1D15 NOT INSTALLED
L1D16 NOT INSTALLED
ANALOG LIST – DETECTORS
A = 1
F = 1
I = 1
N = 0
UP
STATUS CHANGE BACK
DAY MODE
CHANGE
BACK
Actions:
Use the UP and DOWN buttons to select
detector.
Use the STATUS button to perform a live point
read on the detector.
Use the CHANGE button to display soft buttons
ADD and REMOVE . Use ADD to edit the
detectors setting and/or change its name.
Press BACK to return to the previous screen.
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling
functions.
