Panel Operation
32 AFP-2800/2802 Manual – P/N 11249 11-Mar-08
6.3.3.7.1.1 Service Menu – List – List – Analog – Detectors – Status
This screen will show a reading of the selected Analog addressable detector updated every 3 seconds, 255 times.
The detector’s current configuration is displayed together with “live readings” as shown below.
Heat Detector Smoke Detector
L1D2 (Z001) > APARTMENT 1 BATHROOM
Poll Mode > FlashScan Mode
Programmed As > HEAT
Actual Device > HEAT
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
Detector Values:
Alarm = 0% Peak Temperature = 30 C
Temperature = 24 C Day Alm Sensitivity= 5
Night Alarm Sens = 1
Device Scanned 255 Times .
ANALOG MENU – STATUS
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
PREV
TEST Menu
DAY MODE
NEXT RESET
L1D3 (Z990) > APARTMENT 1 BEDROOM
Poll Mode > FlashScan Mode
Programmed As > PHOTO-OPTICAL
Actual Device > PHOTO-OPTICAL
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
Detector Values: (Needs Cleaning)
Alarm = 0% Peak Alarm Value = 10%
Prealarm = 0% Day Alm Sensitivity = 5
Compensation = 81% Day PreAlarm Sens = 5
Night Alarm Sens = 1
Night PreAlarm Sens = 1
Device Scanned 255 Times .
ANALOG MENU – STATUS
A = 0
F = 0
I = 0
N = 0
20 JULY 2002 14:44:37
DAY MODE
PREV
TEST MenuNEXT RESET
Note: “:Zxxx” is displayed after the descriptor, xxx is the zone number mapped to the detector. A zone number of 0
is an indication that the detector is not mapped to a zone.
Actions:
 Press the PREV buttons to move to the previous installed point.
 Press the NEXT buttons to move to the next installed point.
 Press the TEST button to enter test menu for the detector.
 Press the RESET button to re-initialise the detector.
 Press MENU to return to the Analog Menu screen.
Explanations of terms:
Variable Range Description
Poll Mode
FlashScan or CLIP Shows the current polling protocol being used. FlashScan = 10
detectors at a time, CLIP = 1 detector at a time. Polling mode is
auto sensed at start-up
Programmed As 8 Types Detector type programmed into panel
Actual Device 8 Types Detector type physically seen on loop.
Device State Normal/Active/Alarm Shows alarm or activated condition of point.
Device Status 23 fault types Detailed description of fault condition. i.e.: “No Response”
LED Status 4 Types Polling, On, Off, Polling ID
Alarm % Current Percentage of alarm or Degree Celsius
Pre-alarm % Current Percentage of Pre-alarm
Peak Alarm Value % or
O
C Highest reading since last reset.
Drift Compensation % Please refer to page 106 for explanation information on Drift
Compensation.
Sensitivities 1-9 Detector sensitivity for day/night, alarm/pre-alarm. Please refer to
page 103 for explanation information on sensitivity settings.
