System Faults
Table G.2 gives a description of each system fault.
System
Fault
Index
System Fault Name
System
Fault
Index
System Fault Name
System
Fault
Index
System Fault Name
System
Fault
Index
System Fault Name
504 NO POWER SUPPLY INST 611 PHONE CHANNEL LIMIT EXCEEDED 648 PRIMARY AMP 2 TRIP 685 VESDANET FAULT
505 LOOP 1-2 COMM FAILURE 612 NCM SNIFFER MODE ACTIVE 649 PRIMARY AMP 3 TRIP 686 RESERVED
506 LOOP 3-4 COMM FAILURE 613 NCM CONNECTION LIMIT EXCEEDED 650 PRIMARY AMP 4 TRIP 687 DOOR INTERLOCK FAULT
507 LOOP 5-6 COMM FAILURE 614 HARDWARE MISMATCH 651 BACKUP AMP 1 TRIP 688 ANNUN 01 TYPE MISMATCH
508 LOOP 7-8 COMM FAILURE 615 DAL DEVICE NO ANSWER 652 BACKUP AMP 2 TRIP 689 ANNUN 02 TYPE MISMATCH
509 LOOP 9-10 COMM FAILURE 616 PRIMARY AMP 1 HARDWARE FAILURE 653 BACKUP AMP 3 TRIP 670 ANNUN 03 TYPE MISMATCH
510 TEST PROGRAM UPDATE 617 PRIMARY AMP 2 HARDWARE FAILURE 654 BACKUP AMP 4 TRIP 671 ANNUN 04 TYPE MISMATCH
511-571 RESERVED 618 PRIMARY AMP 3 HARDWARE FAILURE 655 DSBUS 1 AC FAIL 672 ANNUN 05 TYPE MISMATCH
572 GROUND FAULT PORT A 619 PRIMARY AMP 4 HARDWARE FAILURE 656 DSBUS 2 AC FAIL 673 ANNUN 06 TYPE MISMATCH
573 GROUND FAULT PORT B 620 BACKUP AMP 1 HARDWARE FAILURE 657 DSBUS 3 AC FAIL 674 ANNUN 07 TYPE MISMATCH
574 AMPLIFIER FAULT 621 BACKUP AMP 2 HARDWARE FAILURE 658 DSBUS 4 AC FAIL 675 ANNUN 08 TYPE MISMATCH
575 AUXIN FAULT 622 BACKUP AMP 3 HARDWARE FAILURE 659 DSBUS 1 HIGH BATT 676 ANNUN 09 TYPE MISMATCH
576 DIGIN FAULT 623 BACKUP AMP 4 HARDWARE FAILURE 660 DSBUS 2 HIGH BATT 677 ANNUN 10 TYPE MISMATCH
577 FFT FAULT 624 DSBUS 1 COMMFAIL 661 DSBUS 3 HIGH BATT 678 ANNUN 11 TYPE MISMATCH
578 REMOTE MIC FAULT 625 DSBUS 2 COMMFAIL 662 DSBUS 4 HIGH BATT 679 ANNUN 12 TYPE MISMATCH
579 DAP PORT A FAILURE 626 DSBUS 3 COMMFAIL 663 DSBUS 1 LOW BATT 680 ANNUN 13 TYPE MISMATCH
580 DAP PORT B FAILURE 627 DSBUS 4 COMMFAIL 664 DSBUS 2 LOW BATT 681 ANNUN 14 TYPE MISMATCH
581 DAA NO ANSWER 628 AA FAULT BUS FAIL 665 DSBUS 3 LOW BATT 682 ANNUN 15 TYPE MISMATCH
582 LOCAL MIC FAULT 629 NFN PAGING CHAN LIMIT EXCEEDED 666 DSBUS 4 LOW BATT 683 ANNUN 16 TYPE MISMATCH
583 LOCAL PHONE FAULT 630 BACKUP AMP LIMIT 667 DSBUS 1 SELF TEST FAIL 684 ANNUN 17 TYPE MISMATCH
584 ANALOG OUTPUT A FAULT 631 PRIMARY AMP 1 LIMIT 668 DSBUS 2 SELF TEST FAIL 685 ANNUN 18 TYPE MISMATCH
585 ANALOG OUTPUT B FAULT 632 PRIMARY AMP 2 LIMIT 669 DSBUS 3 SELF TEST FAIL 686 ANNUN 19 TYPE MISMATCH
586 ANALOG OUTPUT C FAULT 633 PRIMARY AMP 3 LIMIT 670 DSBUS 4 SELF TEST FAIL 687 ANNUN 20 TYPE MISMATCH
587 ANALOG OUTPUT D FAULT 634 PRIMARY AMP 4 LIMIT 671 PRIMARY AMP 1 FAIL 688 ANNUN 21 TYPE MISMATCH
588 FLASH IMAGE ERROR 635 BACKUP AMP 1 LIMIT 672 PRIMARY AMP 2 FAIL 689 ANNUN 22 TYPE MISMATCH
589 POWER SUPPLY FAULT 636 BACKUP AMP 2 LIMIT 673 PRIMARY AMP 3 FAIL 690 ANNUN 23 TYPE MISMATCH
590 AMPLIFIER LIMIT 637 BACKUP AMP 3 LIMIT 674 PRIMARY AMP 4 FAIL 691 ANNUN 24 TYPE MISMATCH
591 AMPLIFIER SUPERVISION 638 BACKUP AMP 4 LIMIT 675 BACKUP AMP 1 FAIL 692 ANNUN 25 TYPE MISMATCH
592 DAA ADDRESS CONFLICT 639 PRIMARY AMP 1 OVERCURRENT 676 BACKUP AMP 2 FAIL 693 ANNUN 26 TYPE MISMATCH
593-603 RESERVED 640 PRIMARY AMP 2 OVERCURRENT 677 BACKUP AMP 3 FAIL 694 ANNUN 26 TYPE MISMATCH
604 DATABASE CORRUPTED 641 PRIMARY AMP 3 OVERCURRENT 678 BACKUP AMP 4 FAIL 695 ANNUN 27 TYPE MISMATCH
605 AUDIO LIBRARY CORRUPTED 642 PRIMARY AMP 4 OVERCURRENT 679 BACKUP AMP NOT INSTALLED 696 ANNUN 28 TYPE MISMATCH
606 DATABASE INCOMPATIBLE 643 BACKUP AMP 1 OVERCURRENT 680 BACKUP AMP 1 NOT
INSTALLED
697 ANNUN 29 TYPE MISMATCH
607 AUDIO LIBRARY INCOMPATIBLE 644 BACKUP AMP 2 OVERCURRENT 681 BACKUP AMP 2 NOT
INSTALLED
698 ANNUN 30 TYPE MISMATCH
608 DAA DOWNLOAD IN
PROGRESS
645 BACKUP AMP 3 OVERCURRENT 682 BACKUP AMP 3 NOT
INSTALLED
699 ANNUN 31 TYPE MISMATCH
609 RESERVED 646 BACKUP AMP 4 OVERCURRENT 683 BACKUP AMP 4 NOT
INSTALLED
700 ANNUN 32 TYPE MISMATCH
610 RESERVED 647 PRIMARY AMP 1 TRIP 684 MODBUS COMMUNICATIONS
FAULT
701 DISPLAY COMM LOSS
Table G.1 System Fault Names and Codes (2 of 2)
SYSTEM FAULTS
FAULT MESSAGE TYPE FAULT DESCRIPTION
AA FAULT BUS FAIL The AA Fault Bus has failed to communicate with the fire panel. Check wiring and source.
AC FAIL Loss of AC power to DAA. Investigate whether there is an AC power loss, or whether the DAA-
PS is correctly installed and wired.
ADV WALK TEST There is an Advanced Walk Test in progress.
AMPLIFIER LIMIT A digital audio amplifier is overloaded. Remove outputs to lower the load on the speaker
circuits. See the digital audio amplifier manual for more information.
AMPLIFIER SUPERVISION The digital audio amplifier’s internal supervision is not working. Call Technical Services.
AMPLIFIER FAULT The DAA is in fault. The output is overloaded or the amplifier is damaged. Remove outputs to
determine if the DAA was overloaded. If it still does not work, call Technical Services.
ANALOG OUTPUT x FAULT A fault has occurred on DVC-AO analogue output x (1 - 4). The analogue output is configured
for Style 7, but no audio signal is returned. Investigate and fix.
ANNUN x NO ANSWER The annunciator at address x is not responding.
ANNUN x FAULT The annunciator at address x is in fault.
ANNUN x TYPE MISMATCH The annunciator at address x does not match the annunciator type programmed at that
address. Investigate and fix.
AUDIO LIBRARY CORRUPTED The DVC’s audio library is corrupted. Re-create and/or re-download an intact database.
AUDIO LIBRARY INCOMPATIBLE The version is incompatible with the database and/or the application version.
Table G.2 System Fault Descriptions (1 of 4)
