132 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
System Faults
PROG MODE ACTIVATED A user is currently using the panel’s programming menus.
REMOTE DISPLAY x NO ANSWER The remote display at address x is not responding.
REMOTE DISPLAY x FAULT The remote display at address x is in fault.
REMOTE MIC FAULT The DVC’s remote microphone is in fault. It is installed and supervised, but no signal is coming
from it. Investigate and fix.
SELF TEST FAILED Diagnostic test failed. Service required. Call Technical Services.
SOFTWARE MISMATCH One or more LCM or DAA software revisions do not match other LCMs or DAAs, and/or the
network communications module is not network version 5.0, or LCD-160 software is
incompatible. Update the software as necessary.
OPEN SHORT x LOOP x Service required. Call Technical Services.
CLOSED POS. LOOP x There is an open circuit on the positive side of loop x. Closed wiring is a supervised method of
communicating with addressable devices. If the control panel detects a fault (open only), it will drive
both ends of the loop, maintaining communication in an unsupervised method. The latching fault will
display on the panel as a Closed fault until you correct the condition and press reset.
CLOSED NEG. LOOP x There is an open circuit on the negative side of loop x. Closed wiring is a supervised method of
communicating with addressable devices. If the control panel detects a fault (open only), it will drive
both ends of the loop, maintaining communication in an unsupervised method. The latching fault will
display on the panel as a Closed fault until you correct the condition and press reset.
CLOSED SHORT LOOP x Closed wiring is a supervised method of communicating with addressable devices. If the control
panel detects a fault (open or short), it will drive both ends of the loop, maintaining
communication in an unsupervised method. The latching fault will display on the panel as a
Closed fault until you correct the condition and press reset.
SYSTEM INITIALIZATION One or more devices (detectors or modules) can not report activation. This can occur following
system startup, when exiting Walk Test, or following a device fault of No Response.
VESDA FAULT A fault has occurred on a VESDA node. Possible faults may include: Communication failure on the
VESDA detector loop, incompatible VESDA software versions, or VESDA configuration error.
SYSTEM FAULTS
FAULT MESSAGE TYPE FAULT DESCRIPTION
Table G.2 System Fault Descriptions (4 of 4)
