AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 131
System Faults
FFT FAULT There is a short or open on an FFT riser on a Digital Audio Loop. Check that the DVC’s 4-wire
switch is set properly and that there is an end-of-line resistor in place for 2-wire operation.
GROUND FAULT A ground fault has occurred within the panel.
GROUND FAULT LOOP x There is a ground fault on loop x.
GROUND FAULT PORT x A ground fault has occurred on DAP x (A or B).
HARDWARE MISMATCH The device installed does not match what was previously installed. Install the correct device.
INTERNAL RAM ERROR The internal RAM test failed. Service required.
INVALID NODE TYPE MAPPED An invalid node type has been mapped to the AFP-3030 for Network Display Mode. Check
network mapping and correct.
INTERNAL RAM ERROR The internal RAM test failed. Service required.
LCD80 SUPERVISORY Communication has been lost with an LCD-80.
LOADING...NO SERVICE A program or database download is in progress. The panel is NOT providing fire protection
during the download. Proper authorities should be notified while a download is in progress so
that other means of fire protection can be supplied.
LOCAL MIC FAULT The DVCs local microphone is in fault. There is no communication, or paging has been enabled
for over 28 seconds and no signal has been received. Investigate whether the mic is plugged
into the DVC, or whether there is a problem with the local mic.
LOCAL PHONE FAULT The DVC’s local FFT handset is in fault. There is no communication, or paging has been
enabled for over 28 seconds and no signal has been received. Investigate whether the handset
is plugged into the DVC, or whether there is a problem with the handset.
LOOP x- x COMM FAILURE Loops x and x are not responding. The LCM and LEM for those loops must be serviced.
MAN EVAC INITIATED Local initiation of DRILL
MAN EVAC RECEIVED Network initiation of DRILL
MANUAL MODE ENTERED An annunciator has been placed in manual mode.
MODBUS COMMUNICATIONS
FAULT
The VESDA
®
Gateway can not communicate with the HLI, HLI may be damaged or not
powered, or the VESDA Gateway may be damaged.
NCM COMM LOSS Communication lost between CPU2-3030 or DVC and network communications module.
NCM CONNECTION LIMIT
EXCEEDED
More than two panels have been connected to a high-speed network communications module.
NCM SNIFFER MODE ACTIVE The network is in a diagnostic state.
NETWORK FAIL PORT x Communication lost between NCM Port x and corresponding node.
NETWORK INCOMPATIBILITY The brand of this panel is incompatible with this network.
NETWORK MAPPING LIMIT
EXCEEDED
More than 1 fire panel or more than 4 DVCs has been mapped to the AFP-3030 for Network
Display Mode. Check network mapping and correct.
NFN PAGING CHANNEL LIMIT
EXCEEDED
Multiple paging sources are attempting to page over the NFN, exceeding the limit of one (1).
reduce the number of paging sources to clear this fault.
NFPA 24HR REMINDER This message occurs every day at 11 am if any faults exist.
NVRAM BATT FAULT Battery backup and/or clock backup is low. Replace battery.
NO DEV. INST ON L1 No devices are installed on the system.
NO POWER SUPPLY INST The address of the main power supply has not been entered.
PANEL DOOR OPEN The panel door is open.
PHONE CHANNEL LIMIT
EXCEEDED
The DVC has allocated all its phone channels, and there are still phones ringing in requesting
more channels.
POWER SUPPLY FAULT There is a communication failure with the DAA onboard power supply. Call Technical Services.
PRIMARY AMP x FAIL The Primary Amp at address x has failed. Call Technical Services.
PRIMARY AMP x HARDWARE
FAIL
The Primary Amp at address x has had a hardware failure. Call Technical Services.
PRIMARY AMP x LIMIT The Audio Circuit of the Primary Amplifier at address x has been overloaded or shorted so the
Audio Signal has been attenuated. Check wiring and source and ensure that there are no
shorts.
PRIMARY AMP x OVERCURRENT The Primary Amplifier at address x has overloaded and shut down. Check the total Load
calculations fir the DS-AMP and/or DS-BDA and ensure the total values do not exceed 120
watts.
PRIMARY AMP x TRIP The DS-BDA at DS-BUS address x (1-4) is drawing more current from the power supply than
expected and has been disabled. Refer to the DVC manual for additional troubleshooting.
PRINTER OFF LINE Communication loss with printer. Restore power and/or printer’s online status.
PRINTER PAPER OUT Add paper.
PROGRAM CORRUPTED The database that houses the panel’s programming is corrupt. It must be re-downloaded, or all
programming must be cleared and re-entered. Service required.
SYSTEM FAULTS
FAULT MESSAGE TYPE FAULT DESCRIPTION
Table G.2 System Fault Descriptions (3 of 4)
To Next Page
