10 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Main Menu and Event Counts Screen The Main Menu
Basic Walk Test - The basic test allows a single operator to run audible tests on the panel. All logic
equation automation is suspended during the test. All ACS devices will default to Disable. They
may be enabled by selecting NO at the DISABLE ACS BOARDS soft key on the Walk Test Menu
screen (
Figure 2.5).
Advanced Walk Test - The advanced test allows field-supplied output point programming that will
react to input stimuli such as CBE and logic equations. When points are activated in advanced
testing, each initiating event will latch the input. Release of the latch and subsequent activation of
the next point is controlled through use of the NEXT TEST soft key. All ACS devices default to
disable. They may be enabled by selecting NO at the DISABLE ACS BOARDS soft key on the
Walk Test Menu screen (
Figure 2.5). An advanced test is audible.
An audible test is intended for manual call point verification, magnet-activated tests on input
devices, input and output device and wiring operation/verification. Only devices previously
configured to participate and designated as part of the test through the following screens will make
sound.
Walk Test Activation Indications
FlashScan poll mode - Once the START TEST soft key has been pressed:
• Each intelligent addressable input device will blink its address in red, and each intelligent
addressable output device will blink its address in green. Pattern examples are given below.
• An input device activated in Walk Test latches on steady green for the duration of the test. If
the device is put in fault (for instance, the detector head is removed, then replaced), the LED
will be latched on for the duration of the test.
• An output device activated in Basic Walk Test will remain active and the LED will glow steady
green for
– 4 seconds for alarms
– 8 seconds for faults.
• An output device activated in Advanced Walk Test will remain active and the LED will glow
steady green until the NEXT TEST soft key is pressed.
CLIP poll mode - Once the START TEST soft key has been pressed:
• Intelligent addressable input and output devices continue to blink red as usual until activated.
• An input device activated in Walk Test latches on steady red during activation. If the device is
put in fault (for instance, the detector head is removed, then replaced), the LED will be latched
on for the duration of the test.
• An output device activated during Basic Walk Test will remain active and the LED will glow
steady green (if a FlashScan module) or steady red (if a CLIP module) for
– 4 seconds for alarms
NOTE: Walk Test will not start if any devices are active (i.e., fire alarms, supervisories or
prealarms). To perform a walk test while a device is active, disable the device and press the
System Reset button.
NOTE: In network applications, specific nodes can be excluded from having the ability to force the
fire panel out of Walk Test due to an alarm condition. This is programmable via VeriFire Tools. Refer
to the VeriFire Tools help file.
Address Blink Pattern
8 8 blinks, long stop, 8 blinks, long stop, …
37 3 blinks, stop, 7 blinks, long stop, 3 blinks, stop, 7 blinks, long stop, …
152 15 blinks, stop, 2 blinks, long stop, 15 blinks, stop, 2 blinks, long stop, …
