14 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
Main Menu and Event Counts Screen The Main Menu
Devices Test Selection
Figure 2.8 Devices Test Selection Screen (Detectors)
Soft Keys
START FAULT TEST: Press this key to generate a Fault on the selected detector.
START ALARM TEST: Press to generate an Alarm on the selected detector.
START OBSCURATION TEST: Press to perform an Obscuration Test on the selected Beam
detector. (Beam detectors only.)
START PREALARM TEST: Press to perform a Prealarm Test on the selected device.
ABORT: Press to stop the Walk Test.
Figure 2.9 Devices Test Selection Screen (Modules)
Soft Keys
START FAULT TEST: Press this key to generate a Fault on the selected detector.
START ALARM TEST: Press to generate an Alarm on the selected detector.
FAULT
PROG MODE ACTIVATED
LAKEVIEW GENERAL HOSPITAL
10:22:34A TUE JAN 25, 2011
WALK TEST IN PROGRESS
SETTINGS:BASIC, AUDIBLE, PANEL
START FAULT TEST START PREALARM TEST
START ALARM TEST
START OBSCURATION TEST ABORT
This field will appear only for a beam detector with an integral sensitivity test feature.
FAULT
PROG MODE ACTIVATED
LAKEVIEW GENERAL HOSPITAL
10:22:34A TUE JAN 25, 2011
WALK TEST IN PROGRESS
SETTINGS:BASIC, AUDIBLE, PANEL
START MODULE ACTIVATION TEST
NEXT POINT
PREVIOUS POINT ABORT
This field will appear only for a beam detector with an integral sensitivity test feature.
