Figure 3.20 Sample ACS Point Programming Screen
Soft Keys
POINT: Press this soft key to enter the ACS point number. The format is AxxPyy, where A is the two-
digit device address, P is the two-digit point number. Enter a leading zero for one-digit numbers.
MODE: Press this soft key to enter the ACS mapping mode. Table 3.3 shows the possible mode
choices and descriptions of their functions.
NOTE: The AFP-3030 supports ACM-24AT/ACM-48A annunciators and their expanders with
either 64 or 96 points at an address, as well as LDM-32 annunciators with 64 points at an
address.
ACS POINT PROGRAMMING
POINT: A27P04
MODE: MONITOR
SOURCE: N23L01M037
(MODULE)
NEXT ACCEPT
PREVIOUS BACK
ACS Point
Mode
Function:
The point…
Explanation
NONE … is not programmed. No messages are sent from or received at this point.
LEDs at this point do not light.
CONTROL … will change the state of up to eight control modules
OR (for AFP-3030 only) up to eight general zones to off
or on when its button is pushed.
Selecting this point mode will bring up the Control Point
Select screen (refer to
Figure 3.21).
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
MONITOR … will show the current status of a specified point or
zone.
The Point Active LED is lit if the corresponding mapped
point or zone is active. The Status (fault) LED is on if that
point or zone is in fault. If the point has a button, it has no
effect when pushed.
CO MONITOR … will show the current state of the CO element for the
specified point entered.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
is in fault. This point is specifically used to annunciate the
CO element of the PHOTO/CO detector.
DISABLE … will change the state of a point, zone, or DAA speaker
circuit(s) specified through mapping from enabled to
disabled, or from disabled to enabled, when its button is
pushed.
See Caution below this table.
The Point Active LED is lit if the corresponding mapped
point or zone is active. The Status (fault) LED is lit only if
that point or zone is disabled.
ACKNOWLEDGE … will act like an Acknowledge soft key or button on the
panel, acknowledging an event when its button is
pushed.
The Point Active LED is lit when there are any fire alarms
in the system. The Status (fault) LED is lit when there are
faults in the system.
Table 3.3 ACS Point Mapping: Explanation of Point Modes (1 of 2)
