AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 35
Panel Program PrealarmProgram
SOURCE: Pressing this soft key will select the SOURCE field and also toggle between display
formats if a point value is allowed. Enter a point or zone, or the panel’s node number if the mode
type is a system function such as acknowledge or reset.
Up to eight sources are allowed when CONTROL mode is chosen.
For ALL CALL, PAGE INACTIVE, PAGE EVAC, and PAGE ALERT modes, enter the node number
of the DVC where the source is connected.
SILENCE … will act like the Signal Silence button on the panel,
silencing all silenceable outputs when its button is
pushed.
The Point Active LED is lit if all silenceable outputs have
been silenced. The Status (fault) LED is lit if not all
silenceable outputs have been silenced after the button
is pushed.
RESET … will act like the System Reset button on the panel,
resetting the panel when its button is pushed.
No LED will ever light at this point.
ENABLE
PAGING FROM
___
...will cause the associated input to become an active
audio source on Noti•Fire•Net. The user may then
choose to activate specific PAM points on remote Digital
Voice Commands to use this network input, or to perform
a paging function such as ALL CALL from this input.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
ALL CALL This point will activate ALL CALL. (Speaker Circuits will
turn on according to programming) to a DVC only.
Mapping must be to a DVC node.
If an AMG is connected to this panel, ALL CALL can be
activated ONLY by the ALL CALL switch on the AMG. Do
not program any other annunciators for ALL CALL.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
PAGE
INACTIVE
...will, when pressed after a Page Enable, allow PAGE
INACTIVE paging from that source. The Special Paging
Function map programming at the DVC will receive the
page function.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
PAGE EVAC ...will, when pressed after a Page Enable, allow Page
Evac paging from that source. The Special Paging
Function map programming at the DVC will receive the
page function.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
PAGE ALERT ...will, when pressed after a Page Enable, allow Page
Alert paging from that source. The Special Paging
Function map programming at the DVC will receive the
page function.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
FFT-NFN ....will, when pressed:
• Notify a DVC in the map format
Nxxx,Nxxx,NxxxLyyMzzz or Nxxx,Nxxx,NxxxAyyT to
open the FFT-NFN link and turn on the mapped FFT
point or riser. A second press will notify the DVC to
turn off that FFT point or riser and determine whether
the FFT-NFN link should be closed or remain open.
• Notify a DVC in the map format Nxxx,Nxxx to close
or open the FFT-NFN link between two DVCs.
The Point Active LED is lit if a corresponding mapped
point is active. The Status (fault) LED is on when a point
or zone is in fault.
ACS Point
Mode
Function:
The point…
Explanation
Table 3.3 ACS Point Mapping: Explanation of Point Modes (2 of 2)
!
CAUTION:
WHEN A DISABLED OUTPUT IS ENABLED, IT WILL BE AFFECTED BY CONDITIONS EXISTING
IN THE SYSTEM THAT WOULD NORMALLY AFFECT IT. FOR EXAMPLE, WHEN A CONDITION
EXISTS IN THE SYSTEM THAT WOULD NORMALLY TURN THE OUTPUT ON, THE OUTPUT
WILL TURN ON WHEN IT IS ENABLED.
