36 AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015
PrealarmProgram Panel Program
For TELEPHONE mode, enter the address of the telephone module point using the format
NxxXLyyMzzz. Use the format NxxxAyyT (where xxx = the node number and yy = the digital
audio amplifier address) for FFTs on risers that have no FTM modules installed.
FFT-NFN mode sources:
• format Nxxx,Nxxx,NxxxLyyMzzz: Telephone control module (NxxxLyyMzzz) preceded by
the node numbers of the two DVCs (Nxxx,Nxxx) that will communicate over the FFT-NFN
link.
• format Nxxx, Nxxx: numbers of the two DVCs that will communicate over the FFT-NFN link.
• format NxxxAyyT: Use this address (N = the DVC node number and A = the DAL device
address on the digital audio loop) when no telephone control modules are installed on a
DAL device’s FFT riser.
Refer to the FFT-NFN section of the DVC manual for programming and application examples.
ACCEPT: Press this soft key to save the changes to the point displayed.
BACK: Press this soft key to exit the screen without saving, and return to the ACS Programming
Screen.
Control Point Select
Figure 3.21 Control Point Select Screen
Control source field entries may be:
• SLC modules in the format NxxxLyyMzzz. xxx = FACP node number, yy - the SLC loop
number, zzz - module loop address.
• General zones in the format NxxxZyyy. xxx = FACP node number, yyy = General zone
number (Z001 - Z999, not Z000. Zone 0 is not valid).
• Prioritized Audio Matrix (PAM) speaker points, in the format NxxxIyyyyAzzSn, where xxx
= the DVC node number, yyyy = the input number in the PAM, zz = the DAA address on the
Digital Audio Loop (01 through 32), and n = the DAA speaker circuit (1 through 4).
CONTROL POINT SELECT
N000I0001A00S1 XXX
XXX XXX
XXX XXX
XXX XXX
POINT SELECT ACCEPT
NOTE: A zone with a node number of zero (0) will be a local zone.
!
CAUTION: DO NOT MIX GENERAL ZONES WITH OTHER SOURCE TYPES FOR AN ACS
CONTROL POINT. PROGRAM UP TO EIGHT GENERAL ZONES OR UP TO EIGHT OTHER
CONTROL POINT TYPES.
