Panel Program PrealarmProgram
Soft Keys
All soft keys function like they do on the ACS Point Programming Screen.
ACM-ZM Point Mapping
Refer to the following table for ACM-ZM predefined points.
ACM-8RA Point Mapping
Refer to the following table for ACM-PSI predefined points:
ACS Point: Point Text: Point Type: Explanation:
AXP1 System Normal LED N/A This point is active when the fire panel is System Normal. This point will
extinguish if an alarm, fault, or supervisory condition occurs
AXP2 Common Alarm LED N/A This point will activate when a fire alarm is present on the fire panel or any
fire panels mapped to the fire panel in Network Display Mode. This point will
extinguish once the fire alarm condition is cleared and the panel or panels
are reset
AXP3 Sprinkler LED N/A A non-fire alarm is present on the fire panel, but the Brigade Interface output
on the ACM-ARE has not yet activated
AXP4
*
Common Defect LED N/A This point will activate when a device or system fault is present on the fire panel or
any fire panels mapped to the fire panel in Network Display Mode
AXP5
*
Zone 1 Alarm N/A An alarm was received from the fire panel on Zone 1
AXP6
*
Zone 2 Alarm N/A An alarm was received from the fire panel on Zone 2
TO
AXP75
*
Zone 71 Alarm N/A An alarm was received from the fire panel on Zone 71
AXP76
*
Zone 72 Alarm N/A An alarm was received from the fire panel on Zone 72
AXP77 Trial Evacuation Key Supervisory Press to initiate an Evacuation on the fire panel and activate all alarm
devices. A supervisory condition will be displayed on the fire panel. Press a
second time to de-activate the evacuation and clear the supervisory event
from the fire panel.
Note: This only operates on the New Zealand panel.
AXP78 Brigade Silence Fault Press to initiate a signal silence on the fire panel and silence all active alarm
devices. A fault condition will be displayed on the fire panel. Press a second
time to de-active the brigade silence and clear the fault from the fire panel.
Note: This only operates on the New Zealand panel.
AXP79 Door Open Input Supervisory Press to initiate a supervisory event on the fire panel and display PANEL
DOOR OPEN. Press a second time to de-activate and clear the supervisory
event from the fire panel.
SYSTEM FAULT Door Interlock System
Fault
Fault This will activate when door is closed and either of the following is true:
-the panel is silenced
-the Evacuation key, Brigade Silence, Door Holder Disable, Auxiliary Disable,
ARE Disable Input, or Alarm Device key is active.
Note: This only operates on the New Zealand panel.
Table 3.4 ACS Point Mapping: Explanation of ACM-ZM Point Modes
* These points are can be edited from their default settings to monitor other zones, devices, or points.
ACS Point: Point Text: Point Type: Explanation:
AXXP01 Relay Output 1 Monitor -
Zone 1
Relay will energise when Zone 1 on the local fire panel is active.
AXXP02 Relay Output 2 Monitor -
Zone 2
Relay will energise when Zone 2 on the local fire panel is active.
Table 3.5 ACS Point Mapping: Explanation of ACM-8RA Point Modes (1 of 2)
