AFP-3030 Programming Manual — P/N DOC-01-032:A 26/06/2015 53
Point Program PrealarmProgram
Detector Point Programming (3)
Press the MORE soft key on the Detector Point Programming (3) screen to display this screen.
Figure 3.38 More Detector Point Programming (3) Screen
Soft Keys
LOW TEMP ENABLE: Press this softkey to select YES or NO to enable the Low Temperature
Warning for the PHOTO/CO detector. This field is only available when programming a
PHOTO/CO smoke detector.
PREALARM: Press this softkey to select ALERT or ACTION for the Prealarm function. Refer to
the section on Prealarm in
Appendix C, “Intelligent Sensing Applications” for a description of
Alert and Action.
SILENCEABLE: This field determines whether the user can manually silence a detector’s
activated sounder/relay base. Values are as follows:
INTELLIGENT SOUNDER: Press this softkey to select YES if an Intelligent Sounder Base is
installed for this detector.
SOUNDER BASE SETUP: Press this softkey to proceed to the Sounder Base Setup screen. This
option will only be available if the INTELLIGENT SOUNDER is set to YES.
NO Not manually silenceable
YES - RESOUND FIRE Silenceable, resound on fire alarm events Network and Local Resound
YES - RESOUND SUPERV Silenceable, resound on supervisory events Network and Local Resound
YES - NO RESOUND Silenceable, does not resound
DETECTOR POINT PROGRAMMING
L03D123
LOW TEMP ENABLE: YES
PREALARM:ALERT CO PREALARM: YES
SILENCEABLE:NO MORE
INTELLIGENT SOUNDER:YES ACCEPT
SOUNDER BASE SETUP BACK
When programming an aspiration detector, this position will be replaced by “REFERENCE DETECTOR ADDRESS”.
NOTE: In network applications, specific nodes can be excluded from having the ability to initiate a
resound on the local fire alarm panel. This is programmable via VeriFire Tools. Refer to the VeriFire Tools
help file.
NOTE: When programming an aspiration detector, INTELLIGENT SOUNDER is not an option
and SOUNDER BASE SETUP is replaced by REFERENCE DETECTOR ADDRESS.
