THE 220 VAC POWER SUPPLY LINE
The AM6000 control panel requires connection to a separate 220 VAC 50 Hz line, which must be labeled “FIRE
ALARM”.
No other equipment may be powered from the circuit employed for the fire alarm system.
Overcurrent protection for this circuit must comply with local normatives.
Use proper section wire with minimum 600-volt insulation.
TABLE 1 : 220 VAC service line current requirements
The table 1 allows to calculate the total amount of current, in AC amps, that the AC service line must be capable
of supplying to the system.
Page 23 Installation Manual AM-6000-60003.VP
NOTIFIER ITALIA Rev. B.1 Doc. M-180.2-AM6000-ENG
Device
Type
Number of
Devices
Multiply
by
Current in
Amps (each)
Total Current/
Type
Main Power Supply 1 x 0,9 0,9
AVPS-6 ( ) max 1 x 0,45
Total amount of current required
for 220 VAC circuit Amps
