Section 2 Installation
PN 50702:B2 4/14/03 11
Section 2 Installation
WARNING: Use extreme caution when working with the
APS-6R. High voltage and AC line-connected circuits are
present. Turn off and remove all power sources. To reduce
the risk of electric shock make sure to properly ground the
unit.
Introduction
This section contains instructions for mounting, wiring, configuring
and servicing the APS-6R.
Installation topics covered in detail:
Additional information regarding installation may be found in the
appendices.
!
Topic Refer to...
Mounting to a CAB-3/CAB-4
Series Cabinet
Page 12 in "Mounting in
CAB-3/CAB-4 Series
Cabinets"
Field Wiring Page 13 in "Field Wiring an
APS-6R"
Wiring Multiple APS-6Rs Page 15 in "Connecting
Multiple APS-6R Power
Supplies"
Connecting to an ICM/ICE Page 16 in "Connecting the
APS-6R to an ICM/ICE
Module"
Powering a Control Module Page 17 in "Supplying
Power to a Control Module"
Configuring Page 18 in "Configuring the
APS-6R"
Servicing Page 19 in "Servicing the
APS-6R"
