INERTIA-2464
Technical & Programming Manual Page 5
Copyright (c) 1996,
INERTIA FIRE SYSTEMS
PERFORMANCE DATA
27VDC Power Supply.
AC Input 30 VAC +10% - 15%
Output Current 3 AMPS (Incl 1A External)
Output Voltage 27.6 VDC
Current Limit 3 AMPS
Output Ripple 50 mV
Internal 5VDC 2A Power Supply.
This supply's primary function is to power all internal operations of the FIP, ie: Microprocessor, liquid crystal
display, LED's keypad etc.
AC Input 30 VAC +15% or 27.6VDC+15%
Output Current 2.0 AMPS
Output Voltage 5.0 VDC
Current Limit 2.0 AMPS
Output Ripple 150 mV
BATTERY TYPE AND CAPACITIES
ZONES FITTED BATTERIES REQUIRED
24 to 32 2 X 12V 10 A/H
40 to 64 2 X 12V 17 A/H
