Notifier LCD-80 User Manual

46 PN 15037:D2 9/9/02
and 4. AM2020/AFP1010 Note: For the first LCD-80 on the loop, let
the shield coming in from the CCM-1 or DIA float.
When the EIA-485 shield is in conduit
: At each respective LCD-80
enclosure (except the first on the loop), terminate the shield coming in
from the previous LCD-80 at system common. Let the shield going
out to next LCD-80 shield float (no connection). Shield termination
between LCD-80s can only occur at the receiving end—the end
connected to LCD-80 P1 Terminals 2 and 4. AM2020/AFP1010 Note:
For the first LCD-80 on the loop, let the shield coming in from the
CCM-1 or DIA float.

Notifier LCD-80 Specifications

General

Brand	Notifier
Model	LCD-80
Category	Monitor
Language	English
