2.10 Entering Custom Point Labels
Custom point labels may be programmed by entering “0” from the
initial program prompt.
ENTER 1 to 9 FOR 9 CUSTOM MESSAGES OR 0 FOR CUSTOM
POINT LABEL:0
A second prompt will be displayed on the CRT-1 or computer monitor.
LCD-80 set for 20-character labels:
ENTER 1 to 256 FOR CUSTOM POINT LABEL (20
CHARACTERS):
where 1-256 represent zones in the control panel.
Note:
System 5000 is limited to 128 points.
AFP-200 uses Zones 1 to 99 only.
Once a point number has been entered, the LCD-80 screen will
display either the custom zone message (illustrated below) or the last
stored point message.
The label may be changed by backspacing over the existing label and
typing a new one.
LCD-80 set for 20-character labels:
ENTER 1 to 128 FOR CUSTOM POINT LABEL (40
CHARACTERS):
where 1-128 represent zones in the control panel.
Note:
AFP-200 uses Zones 1 to 99 only.
Once a point number has been entered, the LCD-80 screen will
display either the custom zone message (illustrated below) or the last
stored point message.
ZONE 005
ZONE 005
(A01P05)
