2.2 Remote Printer Connections (ACS Mode)
The LCD-80 supports the PRN Remote Printer. This printer provides
a hard-copy printout of status changes within the system and time-
stamps the printout with the current time-of-day and date. The PRN
provides 80 columns of data on standard 9" by 11" tractor-feed paper.
Observe the following requirements when connecting a remote
printer:
• Power-limited but not supervised.
• 50 feet maximum wire length (typical) from the LCD-80 to
printer. Wiring distance limited by cable capacitance (see
EIA-232 standard).
• Only one printer supported per LCD-80.
• Use twisted shielded pair cable suitable for EIA-232
applications.
• This interface is intended for use with UL listed printers, such as
the PRN, that do not connect the EIA-232 Reference line to
chassis ground. This is required to avoid creating an earth-fault
condition.
• All EIA-232 circuit wiring to remain in same room as the
LCD-80.
AFP-200
TB5-1
TB5-2
EIA-485 (+)
EIA-485 (-)
AFP-300, AFP-400,
AFC-600
TB4 (+) left pin
TB4 (-) right pin
EIA-485 (+)
EIA-485 (-)
NCA
TB3 (+) top pin
TB3 (-) bottom pin
EIA-485 (+)
EIA-485 (-)
NFS-640
TB-13 (+)
TB-13 (-)
EIA-485 (+)
EIA-485 (-)
System 500, System 5000,
System 2500
TB2-1
TB2-2
EIA-485 (-)
EIA-485(+)
AM2020/AFP1010
(SIB2048, SIB2048A,
SIBNET)
P5-1
P5-2
P5-3
P5-4
P5-5
P5-6
EIA-485 Common
Earth Ground Chassis
EIA-485 Loop 1(+)
EIA-485 Loop 1(-)
EIA-485 Loop 2(+)
EIA-485 Loop 2(-)
Table 2-3 EIA-485 Control Panel Connections (ACS Mode)
Refer to your control panel manual for illustrations of panel-side terminals.
