48 NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014
Operation of the Control Panel Disabled Points Event
2.12 Disabled Points Event
The control panel indicates disabled points by displaying a screen for each disabled detector, moni-
tor module, and control/relay module. Disabled points do not cause an alarm or any Con-
trol-by-event activity. If more than one point is disabled, the control panel automatically displays
each point in the sequence in which the point was disabled.
When one or more points are disabled, the control panel does the following:
• Holds all disabled output points in the off-state
• Flashes the
SYSTEM TROUBLE LED
•Lights the
POINT DISABLED LED
• Sends a Disabled Point message to the History buffer, installed printer and annunciators
• Displays a message for each disabled point, with DISABLED in the upper left corner of the
LCD as well as other information about the point.
Figure 2.13 Sample Disabled Point Message
Soft Keys
ACKNOWLEDGE: Press to acknowledge the disable message.
MORE INFORMATION: Press to view more information on the disabled point.
PROGRAM/ALTER STATUS: A password is required to enter these menus.
!
CAUTION:
WHEN A ZONE IS DISABLED, ANY INPUT AND OUTPUT DEVICES MAPPED TO THE ZONE
ARE DISABLED IF THE ZONE IS THE POINT’S PRIMARY ZONE. (THE PRIMARY ZONE IS THE
ZONE IN THE FIRST POSITION OF THE ZONE MAP.)
DISABLED
ELEVATOR LOBBY EAST WING
FIRST FLOOR DOOR TAMPER
11:58:45A TUE JAN 25, 2011 L01M134
EVENT COUNTS
FIRE ALARMS:000 PREALARM:000 TROUBLE:000
SUPERVISORY:000 SECURITY:000 DISABLE:001
11:59:35A TUE JAN 25, 2011
ACKNOWLEDGE SIGNAL SILENCE
MORE INFORMATION SYSTEM RESET
PROGRAM/ALTER STATUS MAIN MENU

Notifier NFS2-3030 Specifications

General

Type	Intelligent Fire Alarm Control Panel
Power Supply (6 amps total system power)	6 amps total system power
SLC Loop Voltage	24V DC
NAC Voltage	24V DC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes, via NOTI-FIRE-NET
Programming	Via VeriFire Tools
Power Supply	120V or 240V AC, 50/60 Hz
Battery Backup	Yes
Communication Ports	RS-232, USB
SLC Loops	1 or 2
NAC Outputs	4
Operating Voltage	24V DC nominal
Number of Signaling Line Circuits (SLC)	2
SLC Loop Current	0.5 A max per loop
Number of Notification Appliance Circuits (NAC)	4
Total NAC Current	6 amps
Number of Relays	4
Relay Contact Rating	2.0 A @ 30 VDC
