Time and Date Range Selection for All Events Viewing and Printing History Information
4.2 Time and Date Range Selection for All Events
Pressing the Time/Date Interval soft key on the History Select screen displays the Time & Date
Range Select screen. This screen allows for selection of a time period that defines the range of
events to be viewed and/or printed.
Figure 4.2 Time & Date Range Select Screen
Display
See description in Section 4.1, “Events History”, on page 65 for lines 1-5.
Soft Keys
START TIME: - Use the keypad to enter a start time for event viewing in the following format:
HH:MMA/P DDD MM/DD/YY
END TIME: - Use the keypad to enter an end time for event viewing.
EVENT TYPE: - Press this soft key to scroll through the following: ALL EVENTS, ALARMS
ONLY, TROUBLES ONLY, SUPERVISORY ONLY, SECURITY ONLY, OTHER ONLY. Stop scroll-
ing at the desired event type.
ACCEPT: - When entries are made, press this soft key to proceed to the All Events in Interval
Screen.
All Events in Interval Screen
This screen is the same as the Event History screen, except for its title. Refer to Figure 4.1 on page 66.
4.3 Point Range Select for All Events in Range
Pressing the Point Range soft key on the Local History Select screen displays the Point Range
Select screen. This screen allows for selection of a beginning and an end point that defines the
range of events to be viewed and/or printed.
Range is selected in the following order:
1. Loop 1 Detectors
2. Loop 2 Detectors, etc.…
3. Loop 10 Detectors
4. Loop 1 Modules
5. Loop 2 Modules, etc. …
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A TUE JAN 25, 2011
TIME & DATE RANGE SELECT
START TIME: 12:00A THU 01/10/07
END TIME: 02:00P MON 01/14/08
EVENT TYPE: ALL EVENTS ACCEPT
BACK
