68 NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014
Viewing and Printing History Information Point Range Select for All Events in Range
This FACP can have up to 10 loops, which would all follow the above order for range selection.
20. Loop 10 Modules
The range selected below includes all supervisory event types for every point: the selection begins
with the first detector on loop one and ends with the last module on loop 10.
Figure 4.3 Point Range Select Screen
Display
See description in Section 4.1, “Events History”, on page 65 for lines 1-5.
Soft Keys
START POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter a start
point for event viewing.
END POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter an end
point for event viewing.
EVENT TYPE: - Press this soft key to scroll through the following: ALL EVENTS, ALARMS
ONLY, TROUBLES ONLY, SUPERVISORY ONLY, SECURITY ONLY, OTHER ONLY. Stop scroll-
ing at the desired event type.
ACCEPT: - When entries are made, press this soft key to proceed to the All Events in Range
Screen.
All Events in Range Screen
This screen is the same as the Event History screen, except for its title. Refer to Figure 4.1 on page 66.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A TUE JAN 25, 2011
POINT RANGE SELECT
START POINT:
L01D001 (DETECTOR)
END POINT:
L10M159 (MODULE)
EVENT TYPE: SUPERVISORY ACCEPT
BACK

Notifier NFS2-3030 Specifications

General

Type	Intelligent Fire Alarm Control Panel
Power Supply (6 amps total system power)	6 amps total system power
SLC Loop Voltage	24V DC
NAC Voltage	24V DC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes, via NOTI-FIRE-NET
Programming	Via VeriFire Tools
Power Supply	120V or 240V AC, 50/60 Hz
Battery Backup	Yes
Communication Ports	RS-232, USB
SLC Loops	1 or 2
NAC Outputs	4
Operating Voltage	24V DC nominal
Number of Signaling Line Circuits (SLC)	2
SLC Loop Current	0.5 A max per loop
Number of Notification Appliance Circuits (NAC)	4
Total NAC Current	6 amps
Number of Relays	4
Relay Contact Rating	2.0 A @ 30 VDC
