NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014 61
Special Function Zone Read Status
3.11 Special Function Zone
When a special function zone address is entered into the Point Select Screen and the ACCEPT soft
key is pressed, the following screen will display:
Figure 3.12 Special Function Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 52.
Line 7 - The special zone number and function is displayed here.
3.12 Trouble Zone
When a trouble zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display:
Figure 3.13 Trouble Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 52.
EQUATION: The equation for this trouble zone is displayed here.
Line 15 - Current time and date.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124ZF03
AUTOMATIC INACTIVE
SPECIAL ZONE NUMBER 03 ZF03
SECURITY
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124ZT008
AUTOMATIC INACTIVE
TROUBLE ZONE NUMBER 008 ZT008
EQUATION:
AND(T15,T16)
10:22:34A TUE JAN 25, 2011
BACK

Notifier NFS2-3030 Specifications

General

Type	Intelligent Fire Alarm Control Panel
Power Supply (6 amps total system power)	6 amps total system power
SLC Loop Voltage	24V DC
NAC Voltage	24V DC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes, via NOTI-FIRE-NET
Programming	Via VeriFire Tools
Power Supply	120V or 240V AC, 50/60 Hz
Battery Backup	Yes
Communication Ports	RS-232, USB
SLC Loops	1 or 2
NAC Outputs	4
Operating Voltage	24V DC nominal
Number of Signaling Line Circuits (SLC)	2
SLC Loop Current	0.5 A max per loop
Number of Notification Appliance Circuits (NAC)	4
Total NAC Current	6 amps
Number of Relays	4
Relay Contact Rating	2.0 A @ 30 VDC
