NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014 55
Photo/CO Detector Read Status
Display
Lines 1 through 5 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 52.
Line 6 - Refer to the description for Status in Section 3.2, “Smoke Detector”, on page 52. The
MORE option will only be displayed when performing a Read Status on a Photo/CO detector. Refer
to the
MORE option screen below for further details.
Lines 7 through 14 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 52.
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
Figure 3.5 Photo/CO Smoke Detector Screen (2) - Read Status
Lines 1 through 13 - Refer to the descriptions in Section 3.2, “Smoke Detector”, on page 52.
Line 14 - CO - This field represents the level of Carbon Monoxide for the device. The value is in
parts per million.
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A TUE JAN 25, 2011
READ ADDRESS: N124L03D052
CO PRE-ALARM
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 PHOTO/CO
CO:200PPM
10:22:34A TUE JAN 25, 2011
BACK

Notifier NFS2-3030 Specifications

General

Type	Intelligent Fire Alarm Control Panel
Power Supply (6 amps total system power)	6 amps total system power
SLC Loop Voltage	24V DC
NAC Voltage	24V DC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes, via NOTI-FIRE-NET
Programming	Via VeriFire Tools
Power Supply	120V or 240V AC, 50/60 Hz
Battery Backup	Yes
Communication Ports	RS-232, USB
SLC Loops	1 or 2
NAC Outputs	4
Operating Voltage	24V DC nominal
Number of Signaling Line Circuits (SLC)	2
SLC Loop Current	0.5 A max per loop
Number of Notification Appliance Circuits (NAC)	4
Total NAC Current	6 amps
Number of Relays	4
Relay Contact Rating	2.0 A @ 30 VDC
