58 NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014
Read Status Control Module
The second field displays the point status. There are three designations that could appear in this
field.
The device is a control module (an output device) so by referring to the descriptions below, it can
be determined that the point is in a normal state.
Outputs: (Control Modules)
If the point is not in trouble or disabled and the status is Automatic, the display will read:
AUTOMATIC OFF
AUTOMATIC ON
AUTOMATIC OFF-HOOK
If the point has been forced into a manual control state, the display will read as follows. <Trouble
Status> will appear when there is a point trouble.
MANUAL OFF <Trouble Status>*
MANUAL ON <Trouble Status>*
MANUAL OFF-HOOK <Trouble Status>*
If the point is disabled, the display will read as follows. <Trouble Status> will appear when there is
a point trouble.
DISABLED OFF <Trouble Status>*
DISABLED ON <Trouble Status>*
DISABLED OFF-HOOK <Trouble Status>*
If the point is in trouble, the display will read:
TROUBLE OFF <Trouble Status>*
TROUBLE ON <Trouble Status>*
TROUBLE OFF-HOOK <Trouble Status>*
*The field <Trouble Status> will contain one of the device trouble messages listed in
Table 2.1, “Point (Device) Troubles,” on page 29.
Line 11 - blank.
Line 12 - WALK TEST - Displays YES if the device sounds during audible Walk Test.
Line 13 - SILENCEABLE - Displays YES if the operator can manually silence an activated output.
The output resounds for fire.
Line 14 - SWITCH INHIBIT: YES - Displays YES if the operator can not manually activate an output.
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
Point Status
Designation
Description
OFF The point is currently not activated.
ON The point is currently activated.
OFF-HOOK The telephone point is currently off-hook.
