NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014 77
Installed Points Report Screen Printing Reports
RANGE: Press to bring up the following screen, which allows the programmer to choose a range of
installed points to print.
Figure 5.6 Installed Points Menu - Range
Soft Keys
START POINT: Press to place the cursor in this field, and to toggle between the choices, which
appear in print order: DETECTOR (loop1, detector 1 through loop 10, detector 159), MODULE
(loop 1, module 1 through loop 10, module 159), GENERAL ZONE, LOGIC ZONE, RELEASE
ZONE, ACS PTS, SPECIAL ZONE, TROUBLE ZONE. Using the keypad, type in the start point
address.
END POINT: Press to place cursor in this field, and to toggle between the choices as described
above. Using the keypad, type in the end point address.
INSTALLED POINTS MENU
START POINT:
LO1D001 (DETECTOR)
END POINT:
ZT10 _ (TROUBLE ZONE)

Notifier NFS2-3030 Specifications

General

Type	Intelligent Fire Alarm Control Panel
Power Supply (6 amps total system power)	6 amps total system power
SLC Loop Voltage	24V DC
NAC Voltage	24V DC
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes, via NOTI-FIRE-NET
Programming	Via VeriFire Tools
Power Supply	120V or 240V AC, 50/60 Hz
Battery Backup	Yes
Communication Ports	RS-232, USB
SLC Loops	1 or 2
NAC Outputs	4
Operating Voltage	24V DC nominal
Number of Signaling Line Circuits (SLC)	2
SLC Loop Current	0.5 A max per loop
Number of Notification Appliance Circuits (NAC)	4
Total NAC Current	6 amps
Number of Relays	4
Relay Contact Rating	2.0 A @ 30 VDC
