NFS2-3030 Operations Manual — P/N 52546:N1 06/20//2014 79
Alphabetical List Software Type ID Codes
GEN ALARM Control module, XPC-8 circuit, or XP5-C (NAC mode) configured as a Municipal Box
Transmitter for NFPA 72 Auxiliary Fire Alarm Systems applications (MBT-1 required). This
Type ID can also be used for general alarm activation. It is programmed as “switch inhibit”.
GEN PEND Control module, XPC-8 circuit, or XP5-C (NAC mode) that will activate upon receipt of an alarm
and/or trouble condition, and remain in the ON state until all events have been acknowledged
GEN SUPERVIS Control module, XPC-8, or XP5-C (NAC mode) activated under any supervisory condition
(includes sprinkler type). It is programmed as “switch inhibit”
GEN TROUBLE Control module, XPC-8, or XP5-C (NAC mode) activated under any System Trouble condition.
It is programmed as “switch inhibit”
HAZARD ALERT Indicated a hazard condition, tracking
HEAT Adjustable threshold heat detector
HEAT+ Adjustable threshold heat detector with a low temperature warning.
HEAT(FIXED) Intelligent 135ºF thermal sensor detector
HEAT(ROR) 15ºF per minute rate-of-rise detector
HEAT DETECT Monitor for conventional heat detector
HORN CIRCUIT Control module relay module used with NAC with horns
INST RELEASE Control module used with NAC. Always non-silenceable and switch-inhibited
ISOLATED NAC Supervised NAC for notification appliance, used with audio isolators. Activates even if there is
a short on its NAC circuit. Canada installations only.
ISOLATED SPK Supervised NAC for speaker circuit, used with audio isolators. Activates even if there is a short
on its audio circuit. Canada installations only.
LATCH SUPERV Indicates latching supervisory condition
MAN RELEASE Monitor module that provides manual release for a releasing zone through connection to a UL-
listed pull station
MAN REL DELAY Monitor module that provides manual release with a 10 second delay for a releasing zone
through connection to a UL-listed pull station
MONITOR Alarm-monitoring device
MNS CONTROL Activates control module mass notification devices when an MNS event occurs
MNS GENERAL Activates NAC mass notification devices when an MNS event occurs
MNS RELAY Activates relay mass notification devices when an MNS event occurs
MNS SPEAKER Activates speaker mass notification devices when an MNS event occurs
MNS STROBE Activates strobe mass notification devices when an MNS event occurs
NON FIRE Monitors non fire activations
NONRESET CTL Output unaffected by “System Reset” command
PAS INHIBIT Monitor used to inhibit Positive Alarm Sequence (PAS)
P/CO (C SUP) For use with a Photo/CO detector. If the CO element in the detector activates, a supervisory
condition is generated on the fire panel. An activation via the heat or photo element of the
Photo/CO detector will generate an alarm condition on the panel.
P/CO (P SUP)** For use with a Photo/CO detector. If the photo element in the detector activates, a supervisory
condition is generated on the fire panel. An activation via the CO or heat element of the
Photo/CO detector will generate an alarm condition on the panel.
PHOTO/CO For use with a Photo/CO detector. Activation of the CO, photo or heat elements will generate
an alarm condition on the fire panel.
POWER MONITR Monitor for main and auxiliary power supplies
PROCESS AUTO Indicates process condition, tracking
PROCESS MON Indicates process condition, latching
PULL STATION Manual fire-alarm activating device
REL AUDIBLE Activates audio or visual devices steady when releasing starts
REL END BELL Control module used to activate NAC audio or visual device when releasing circuits shut off
REL CKT ULC Control module used to direct outputs to perform a release function as required by ULC
RELAY Form-C relay control module
Software Type ID Code Device
Table A.1 Software Type ID Codes, Alphabetical List (2 of 4)
