3.12 TSP parameters
The boiler operation is controlled by several parameters.
To modify parameters press buttons Reset and - CH together for 3 seconds.
Scroll through the parameters by pressing CH +/- buttons.
As soon as you reach the one to be modied, press ok.
The
symbol turns on to indicate that you can edit the parameter value.
The parameter value can be edited using CH +/- buttons.
To conrm modication press Ok.
To exit the parameter editing mode press button Reset.
Parameter Description
Congurable value
range
Default values Notes
P0 - TSP0 Fuel gas type 0 ÷ 1
According to the
model
0 = LPG; 1 = natural gas
P3 - TSP3 Boiler type selection 1 ÷ 3
According to the
model
1 = combined instantaneous; 2
= heating only; 3 = with water
heater
P6 - TSP6 Ignition power setting 0 ÷ 100 % (min-max) 0%
With P6=0 ignition with ramp.
With P6≠0 ignition at the set
power (P6=1 minimum power ÷
P6=100 maximum power)
P7 - TSP7 CH maximum output 10 ÷ 100% 100% n.a.
P10 - TSP10 Heating output curves 0 ÷ 3 1,5 Resolution 0.05
P11 - TSP11 Heating thermostat timing 0 ÷ 10 min. 4 n.a.
P12 - TSP12 CH power rising ramp timer 0 ÷ 10 min. 1 n.a.
P13 - TSP13
Timer for CH post-circulation,
freeze protection and ue
cleaning function
0 ÷ 180 sec. 30 n.a.
P15 - TSP15
Water hammer protection delay,
congurable
0 ÷ 3 sec. 0 n.a.
P16 - TSP16
Ambient thermostat/remote
control reading delay
0 ÷ 199 sec. 0 n.a.
P17 - TSP17 Multifunction relay setting 0, 1, 3 0
0 = shut-down and malfunction;
1 = ambient thermostat 1
request/Remote control; 2 =
solar; 3 =
ambient thermostat 2 request
P27 - TSP27 Heating timer reset temperature 35 ÷ 78 °C 40 °C n.a.
P28 - TSP28
Hydraulic setting for
management of deviating valve
relay
0 ÷ 1 0
0 = recirculating pump +
deviating valve; 1 = double
pump
P29
Setting of default parameters
(except P0; P1; P2; P17; P28)
0 ÷ 1 0
0 = user parameters; 1 = default
parameters
Tab. 5 Limits to be set for TSP parameters and default values in relation to boiler type (TSP0) - I
