Technical features and dimensions
2.2 Dimensions
400
700
232
118
250
66 60 62 67 82 63
11431
91
81
M
C
G F
R
Fig. 3 Model CTN dimensions
M CH system ow - 3/4"
C DHW outlet - 1/2"
G Gas inlet - 1/2”
F Cold water inlet - 1/2"
R CH system return - 3/4”
