Novoferm DCC-80 - Page 17

Menu8 – profile settings
Menu
item
Entry Selection
80 Selection of the door profile
1-3 Standard fittings (cylindrical drum) 1:fast, 2:medium,
3:slow
4-6 Raised fittings (semi-conical drum) 4:fast, 5:medium,
6:slow
7-9 Vertical runner (full conical drum) 7:fast, 8:medium, 9:slow
81 Force setting opening
STOP Start new force learning cycle cycle (5seconds)
1-10 (5*) Force setting opening
82 Force setting closing
1-10 (4*) Force setting closing
83 Adjusting the closing speed (5seconds)
0 -10% from profile
1* Standard profile
2 +10% from profile
- - STOP Exit menu
* Default setting
Menu9 Service menu
menu
item
Entry Selection
90 Limitation door cycles
0 No limitation
1 1000 cycles
2 1500 cycles
3 2000 cycles
4 2500 cycles
5 3000 cycles
6 3500 cycles
7 4000 cycles
8* 4500 cycles
9 5000 cycles
10 5500 cycles
11 6000 cycles
12 6500 cycles
13 7000 cycles
14 7500 cycles
15 8000 cycles
16 8500 cycles
17 9000 cycles
18 9500 cycles
19 10000 cycles
91 Overall cycle counter output door
98 Firmware version output – serial number – creation date
99 Reset to default setting
STOP 5seconds
- - STOP Exit menu
* Default setting
Door action status display
Display State
⁠
Upper end position OPEN reached
⁠
Door end position has not been reached
⁠
Lower end position CLOSE reached
⁠
Representation of the door opening frequency
⁠
Representation of the door closing frequency
⁠
Force learning cycle indication
⁠
flashing Normal operation, pulsed operation
⁠
flashing Learning cycle for detecting the position of
the photoelectric sensor
⁠
flashing Programming the end position "OPEN"
⁠
flashing Programming the end position "CLOSE"
⁠
sequence Prioritised programmed position is ap-
proached
⁠
flashing Less than 500cycles until next maintenance
⁠
permanently Set service cycles reached. Have mainten-
ance activities carried out.
⁠
permanently A safety sensor is triggered.
⁠
sequence Rotation direction (right / left)
⁠
permanently Prioritised position reached
Novoferm|17
