- 23 -
OPERATION
OPERATING TECHNIQUES & PRECAUTIONS
DO NOT USE THE HAMMER
TOOL AS A PRY BAR
Excessive prying can cause
premature bushing wear and tool or
tie rod breakage. When hammering
materials that allow the tool to
penetrate before breaking, move the
hammer slightly fore and aft to create
a cone-shaped hole. The vented
hole allows trapped dust and heat to
escape, increases the tool
penetration rate into the material,
and prevents overheating the tool tip.
DO NOT HAMMER CONTINU-
OUSLY IN THE SAME
POSITION FOR MORE THAN
30 SECONDS
If the tool cannot break or penetrate
into the material after hammering in
the same position for 30 seconds,
change the working location.
Hammering in the same position for
a long time will reduce the working
efficiency, increase the hydraulic oil
temperature, overheat the tool tip
and accelerate tool wear.
ALWAYS WORK BY
BREAKING TO A FREE FACE
The material must have somewhere
to break. Start at an edge.
ATTENTION
To Next Page
