MACHINE INSPECTION
Now that the machine is unpacked remember to recycle all packing materials.
Inspect the machine for damage or missing components.
If damage is found, contact the freight company to file a freight claim.
MACHINE COMPONENTS LIST
ITEM# DESCRIPTION FIGURE
1 JOYSTICK 1,2,4
2 ARMREST 1,2
3 HORNBUTTON 1,2
4 SNAPSTUDFORHEADRETAININGSTRAP 1
5 DRIVEWHEEL 1,2
6 CASTER 1,2
7 ATTACHMENTPOINTFORHEADRETAININGSTRAP 1
8 PADMOTOR 1
9 HEADLIFTHANDLE 1
10 FLEXIWALLSHIELD 1,4
11
FILTERMEDIABAGCOVER 1,2
12 PADMOTORCOVER 1
13 FOOTPLATE 1
14 SEATSLIDEADJUSTMENT 1,2
15 KEYSWITCH 1,2
16 SEATWITHSAFTEYSWITCH 1,2,4
17 E‐STOPSWITCH 1,2
18 SEATBELT 2
19 WIRINGDIAGRAM 2
20 9%INCLINE 2
21 CIRCUITBREAKER 2
22 NAMEPLATE 2
23 PROP65WARNING 2
24 FILTERMEDIABAG 2
25 HEADRETAININGSTRAP 2
26 FLASHINGWARNINGLIGHT 1
27 BATTERYDISCONECT 3
28 BATTERYCHARGINGPLUG 3
29 BATTERYWARNING 3
30 SEATPLATELIFTHANDLE 3
31 PADHOLDER 4
32 PAD 4
33
BATTERYTRAYDRAINTUBING 5
34 BRAKERELEASELEVER 5
35 TUBINGCONTROLVALVE 5
36 TOUCHPAD 2
PROTECT THE ENVIRONMENT
Please dispose of packaging materials
and used machine components such
as batteries in a safe environmentally
way according to your local waste
disposal regulations.
Always remember to recycle.
