TFTN 085-199 Installation and Operation Manual
Termination Options – Direct Vent Installation
Figure 4-2(a) Two-pipe (Sidewall)
Figure 4-2(b) Low Profile (Sidewall)
Figure 4-2(c) IPEX Concentric (Sidewall)
Figure 4-2(d) PP Concentric (Sidewall)
Location of exhaust and air-intake connections
vary between models, see Figure 4-1.
Location of exhaust and air-intake connections
vary between models, see Figure 4-1.
Location of exhaust and air-intake connections
vary between models, see Figure 4-1.
Location of exhaust and air-intake connections
vary between models, see Figure 4-1.
