Gas Valve and Burner Set-up │ Tx I&O Manual
Figure 9-1 Gas Valve and Venturi Assembly (Tx51-151)
Figure 9-2 Gas Valve and Venturi Assembly (Tx200)
Gas Valve
Line Pressure
Test Port
DO NOT Adjust
Throttle / Input
Adjustment Screw
Manifold Pressure
Test Port
Venturi
DO NOT Adjust
Venturi
Line Pressure
Test Port
Gas Valve
Manifold Pressure
Test Port
Throttle / Input
Adjustment Screw
