19.0 PARTS LIST
For a list of parts that corresponds to the item numbers in the callouts, refer to Table 19-1. Note that some item
numbers may appear more than once in the parts list depending on which model number is being referenced.
Building Owners - Replacement parts are available from your stocking wholesaler. Contact your local Installer
or Wholesaler for assistance with parts.
Wholesalers - Contact NY Thermal Inc. directly when ordering replacement parts, 1-506-657-6000.
Installers - Contact NY Thermal Inc. directly if technical assistance required, 1-800-688-2575.
Figure 19-1(a) Tx Heat Engine and Gas Train
Tx51-151, Tx151C Gas Valve & Blower Assembly
