S. SHIFT. Press and hold this button to access secondary functions (in red lettering)
of other controls on the NV.
1. HEADPHONES SOCKET. Connect your 1/4" or 1/8" headphones to this output for
cueing and mix monitoring.
2. HEADPHONES MIX: Turn to mix between Cue and Program in the Headphone
channel. When all the way to the left, only channels routed to Cue will be heard.
When all the way to the right, only the Program mix will be heard.
3. HEADPHONES SPLIT. When this switch is in the ON position, the headphone audio
will be "split" such that all channels sent to Cue are mixed to mono and applied to the
left headphone channel and the Program mix is mixed to mono and applied to the
right channel. When the switch is in the OFF position, Cue and Program audio will be
"blended" together.
4. HEADPHONES VOLUME. Adjusts the volume level of the headphone output.
