Numatic HGB 3045 - Fitting the Hose Guide; Filling the Clean Water Tank

11
T 01460 68600
Machine Set-up Guide
The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum is switched
o. If you need to remove the U-bend clip for any reason always ensure it is retted correctly before you resume operation.
Fitting the Hose Guide
NOTE: DO NOT push the vacuum hose
onto the oor tool with the oor tool in
the raised position.
Ret vacuum hose to the
Floor tool when nished.
NOTE: Great care must be taken to ensure that contaminants (leaves, hair, dirt, etc.)
are not allowed to enter the clean water tank during the lling process. If using a
bucket or similar, ensure it is always clean and free from debris.
Filling the Clean Water Tank
A
B
C
D
To ll the clean-water tank, use the FLEXI - FILL pipe from either a tap
or hose pipe. (Fig.C).
The large cap can also be used for lling from a bucket, hose or suitable container.
(Fig.A & B).
Fill the clean-water tank to MAX line indication on tank, including cleaning chemicals if
required. Follow chemical manufacturing guide lines.
The clear dump hose at the rear of the machine can be used to see the level of the
clean-water. (Fig.D).
Control of Substances Hazardous to Health (COSHH)
For best results use a non-foaming type of chemical, dilute to the manufacturers specication. For further guidance
on hazardous substances refer to health and safety instructions online.
