Fit the oor tool and retain using the
detent pin.
Push waste collection pipe onto the
oor tool; ensure a tight t.
Raise the oor tool for transit or
lower for cleaning operation using
the lifting handle tted to the back
of the machine.
For tting the oor tool blades
(See Page 21).
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS
!!
450mm / 550mm Brush or a Pad.
Featuring the Nulock brush system.
The brush is simply pushed and twisted to lock, making tting and removal a simple process.
Slide the brush / pad under the brush deck.
Fit the brush / pad onto the Nulock drive chuck, twist to lock the brush / pad in place.
Safety gloves are recommended for the changing of used brushes.
Turn on the clean water tap.
Fitting the Brush / Pad / Turn on water
Fitting the Floor Tool
The oor tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-o feature if the
oor tool gets snagged, whilst in transit.
NOTE: It is easier to t the oor tool if the weight of the machine is resting on the brush. Ensure the brush is tted rst.
