To start: hold either trigger and press the Yellow On / O Switch
once to start the machine.
Direction is controlled using the direction switch tted to the left
side of the handle
Located on the left side of the machine is the Free Wheel lever.
To disengage the brake / drive mechanism, push the lever down.
This allows the machine to be moved in free wheel mode.
Note: When the machine is in free wheel mode the brake
has been disengaged, avoid slopes.
Anti Crush Switch
This machine is tted with an Anti Crush Switch, instantly
stopping and moving the machine forward if accidentally reversed
into the operator.
For a speed boost when moving the machine press the grey fast
moving lever down.
The speed is controlled by the speed control knob tted to the
right hand side of the handle
Note: To drive machine in “Transport Mode” hold down both triggers.
