Machine Set-Up
Fitting the Hose Guide
Ret vacuum hose to the Floor-tool when nished.
Note:
DO NOT push the vacuum hose onto the Floor-tool
with the Floor-tool in the raised position.
The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum is switched
off. If you need to remove the U-bend clip for any reason always ensure it is retted correctly before you resume operation.
250mm - 300mm
Fitting the Floor-tool
The oor-tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-off
feature if the oor-tool gets snagged, whilst in transit.
Push waste collection pipe onto the
oor-tool; ensure a tight t (Fig.15).
Raise the oor-tool for transit or lower for
cleaning operation using the lifting handle
tted to the back of the machine (Fig.16).
For tting the oor-tool blades
(See Page 42).
Note:
It is easier to t the oor-tool if the weight of the machine is resting on the brush. Ensure the brush is tted rst.
Fit the oor-tool and retain using the detent pin (Fig.14).
