NewsCaster VT2 Specifications & Frequency Plans
M17-0002-01A Rev 0.0 22 User Manual
NEWSCASTER VT2 Specifications (continued)
Physical Characteristics:
Size:
Control Unit:................................................19” (48.26 cm) W, 1.75” (4.45 cm) H, 16" (40.64 cm) D
RF Head (Standard Power):.........................9.5” (24.13 cm) W, 5” (12.7 cm) H, 15” (38.1 cm) L
RF Head (High Power): ...............................9.5” (24.13 cm) W, 6.38” (16.2 cm) H, 15” (38.1 cm) L
Weight:
Control Unit:................................................6 lbs (2.72kg)
RF Head (Standard Power):.........................12 lbs (5.45kg)
RF Head (High Power): ...............................16.5 lbs (7.425 kg)
Connectors:
Control Unit:
Video / SDI / DVB-ASI / 70MHz: ...............Type BNC-F
Audio:..........................................................Removable Screw Terminal Strip
IF output to RF Head: ..................................TNC-F (optional Triax)
Optional AUX Power out:............................Terminal Strip
Remote Control (RS232 / RS485): ...............9 Pin D, Female
Remote Control (Ethernet): ..........................RJ-45
Summary Alarm:..........................................Form C on Terminal Strip
Pan / Tilt Power (to RF Head):.....................8 Pin military style connector (Refer to Sec 4 for
cabling)
RF Head:
Optional AUX Power in:..............................MIL-C-26482, 12 Pin
RF Output:...................................................Type “N” female
Polarization:.................................................
Pan / Tilt Power (from Control Unit):...........12 Pin military style connector (Refer to Sec 4 for
cabling)
Pan / Tilt Control (to Pan / Tilt): ..................17 Pin military style connector (Refer to Sec 4 for
cabling)
