Figure 6: Control Unit Rear Panel (AC model)
8A
1
7
8
9
2
3
6
CAUTION – IF INTERFACE (7)
The IF Interface center conductor
carries +48V to power the RF Head. Do
not connect any instruments without
use of a special test cable.
10
NOTE:
Depending on the configuration
ordered, some units may not feature all
of the connectors pictured here.
2.5 Amp Fuse (120 VAC Units)
1.5 Amp Fuse (220-260 VAC Units)
