NewsCaster VT2 Installation
M17-0002-01A Rev 0.0 34 User Manual
Joystick
This optional 6-pin connector (Figure 6,
Detail 9) connects the optional joystick for
Pan & Tilt Motor control. (Refer to Figure 9
for a detailed view and the pin-outs.)
Pan/Tilt Pwr
This optional connector is used to provide
power to the Pan & Tilt Motor. See Figure 6,
Detail 10 for connector location on the
Control Unit. Detailed cabling info for
120 VAC Pan & Tilt systems can be found in
Table 9 and Figure 16. Detailed cabling info
for 12 VDC Pan & Tilt systems is found in
Table 10 and Figure 17.
Figure 10: Control Unit, 160v Pan/Tilt Power
Connector
Figure 11: Control Unit, 12 VDC Pan/Tilt Power
Connector
